Flanged Linear Ball Bearing
Flanged linear ball bearing SJA-LG15-1000-KLThe slider length is 61.4mm, the slider width is 47mm, the maximum dynamic load is 11.27KN, the maximum fixed load 16.80KN guide rail height is 15mm, the bottom width of the guide rail is 15mm, the guide hole distance is 60mm guide and slide combination height is 24mm.
Flanged linear ball bearing SJA-LG15-1000-KLThe slider length is 61.4mm, the slider width is 47mm, the maximum dynamic load is 11.27KN, the maximum fixed load 16.80KN guide rail height is 15mm, the bottom width of the guide rail is 15mm, the guide hole distance is 60mm guide and slide combination height is 24mm.
Q: How can I get the latest price?
A: You can email to our sales for the latest price.
Q: What are the main components of your flanged linear ball bearing?
A: Our flanged linear ball bearing is mainly composed of guide rail, slide block, steel ball, return device, holder, sealing end cover and sealing belt. These components work in concert to ensure high accuracy, high rigidity and stable operation of the linear rails.
Q: How do I choose a linear guide that works for my device?
A: When choosing a flanged linear ball bearing, you need to consider the following key factors: the load size and direction of the equipment, running speed, accuracy requirements, working environment, and installation space. Our professional technical team can provide you with precise suggestions and solutions based on the detailed information you provide. You can also refer to our product selection manual for the performance parameters and application cases of each series of products.
Q: What preparations should be done before the installation of the flanged linear ball bearing?
A: Before installation, please ensure that the installation surface is clean and smooth, free of oil stains, iron chips and other impurities. At the same time, check whether the models and specifications of the guide rail and slide match the equipment, and prepare appropriate installation tools, such as torque wrench, screwdriver, etc. In addition, the installation position and direction of the determined according to the installation drawings and instructions.
Q: What should be paid attention to during the use of the flanged linear ball bearing?
A: In the process of use, to avoid overload operation, strictly in accordance with the rated load of the flanged linear ball bearing operation. At the same time, pay attention to control the running speed, do not exceed the maximum speed specified by the product. Keep the working environment clean and clean the dust and impurities on the guide rail and slide regularly. In addition, the lubrication maintenance in accordance with the specified cycle to ensure good lubrication of the guide rail and slide.
